Solar DCDB (DC Distribution Boxes) · Built to order by DK Traders, Lahore, delivered across Pakistan.
A compact solar DC distribution box for a single PV string feeding one inverter input. It combines a DC breaker and a DC surge protector in one weatherproof enclosure so the string is protected and can be isolated for service.
Tell us your inverter size, number of strings or circuits, and preferred breaker brand, and we will quote the box to match.
Prices are confirmed on enquiry. Call +92-332-0308628 or email info@dktraders.com.pk. The picture is a layout illustration, not a photo of the finished box.
| Type | Solar DC distribution box (DCDB) |
|---|---|
| PV string inputs | 1 |
| Outputs to inverter / MPPT | 1 |
| Rated DC voltage | Up to 1000 V DC (1500 V DC on request) |
| Protection per string | DC MCB (2-pole) or PV fuse + holder |
| Surge protection | DC SPD Type 2 (Class II) |
| Isolation | DC isolator / load-break switch (optional) |
| Enclosure | Polycarbonate or sheet steel, IP65 for outdoor use |
| Wiring | Terminal blocks and busbars sized to the inverter current |
| Made to order | Component brands and ratings chosen to match your array |
Send us your product list or specification and we’ll respond with a formal quotation.
